JASIC Pro ARC 140

The Jasic Arc 140 ARC inverter welder is equipped with the latest IGBT technology and a singular PCB for improved efficiency and easier maintenance.

This technologically advanced inverter is extremely user-friendly and offers reliable and consistent arc performance. The Arc 140 also offers lift TIG functionality making it an ideal choice for maintenance and light fabrication.

The stylish, ergonomic and robust case oozes quality with protective rubber oil finishing to the moulding and handle.

Includes shoulder carrying strap.

The specifications for this ARC welder are listed on the specs tab.

Key Features

  • IGBT Inverter technology - for the professional user
  • ARC / DC Lift TIG
  • 40 Khz inverter frequency, high efficiency
  • Self-adaptive arc force, VRD
  • Compact size, lightweight and modern design
  • Easy arc starting, minimal spatter
  • Stable and reliable arc
  • Auto-compensation for voltage fluctuation
  • Advanced Single PCB construction
  • Generator friendly
Electrical
Volts
220 - 240 Volts
Phase
Single
Hertz
50 Hz
Generator Friendly
Plug Fitted
No
ARC Welder
ARC DC Current Range (A)
10 - 140 Amps
Max Recommended Electrode
3.2 mm
ARC Power Steps
Infinitely Variable
ARC Duty Cycle
35% at 140A @40 °C
ARC No-Load Voltage
63Volts
ARC Efficiency (%)
85%
ARC Power Factor
0.7
ARC Electrode Holder
No
TIG Welder
TIG DC Current Range (A)
10-140 Amps
TIG Start
Lift TIG
TIG Duty Cycle
35% at 140A @40°C
TIG No-Load Voltage (V)
9 Volts
Pre Gas
Valve Control
Post Gas
Valve Control
Slope Up
No
TIG Efficiency (%)
85%
TIG Power Factor
0.7
TIG Torch Included
No TIG torch
General
Protection/Insulation Class
IP 21S/F
Earth Lead
No, not included.
Warranty w/o Registration
24 Months
Warranty w/ Registration
60 Months
Total Weight (Kgs)
5.25 Kgs
